NSD1624-DSPR
| Price: |
$0.45-$0.65 |
$1.1-$1.5 |
Replace parts:
Replacement parts:
Alternative parts:
Pin to pin parts:
|
NSD1624-DSPR |
|
NSD1624 is a high voltage, high side-low side gate driver having capability to deliver 4A source and sink current to drive power MOSFETs or IGBTs. The high side section is designed to endure a DC voltage over 1200V with innovative and proven isolation technology. NSD1624 offers best in class propagation delay, low quiescent current, high negative and dv/dt immunity on SW pin.
Both high side and low side driver section work from 10V to 20V supply voltages having independent under voltage lockout (UVLO) protection. NSD1624 has two independent input pins (HIN and LIN) which are compatible for TTL and
CMOS logic. NSD1624 is available in LGA10, SOP8, and SOP14 package with operating temperature range from -40°C to 125°C
High voltage range: Up to 1200V(SOP14)/700V(SOP8)
Less than 35ns Propagation Delay
Less than 7ns Delay Matching
4 A Source / 6A Sink Currents
High Negative and Transient Immunity up to 150V/ns on SW pin
Gate Drive Supply Voltage from 10V to 17V
TTL and CMOS Compatible Input Logic
UVLO Protection for High-side and Low-side Drivers
Separated Grounds for Logic (SGND) and Driver in SOP14 package
High and Low Voltage Pins Separated for Maximum Creepage and Clearance in SOP14 package Applications
Half-bridge, full-bridge and LLC converters.
High density switching power supplies for Server, Telecom and Industrial
Solar inverters, Motor controls and EV charges
Applications
Half-bridge, full-bridge and LLC converters.
High density switching power supplies for Server, Telecomand Industrial
Solar inverters, Motor controls and EV charges
