NSi1200-DSWVR High Reliability Reinforced Isolated Amplifier
| Price: |
$0.65-$0.75 |
$1.1-$1.3 |
|
Replace parts:
Replace chip:
Replacement parts:
Replacement chip:
Alternative parts:
Alternative chip:
Pin to pin parts:
Pin 2 pin parts:
|
NSi1200-DSWVR |
|
NSI1200 is a high-performance isolated amplifier with output separated from input based on the NOVOSENSE capacitive isolation technology. The device has a linear differential input signal range of ±250mV (±320mV full- scale). The differential input is ideally suited to shunt resistor-based current sensing in high voltage applications where isolation is required. The device has a fixed gain of 8 and provides a differential analog output. The low offset and gain drift ensure the accuracy over the entire temperature range. High common-mode
transient immunity ensures that the device is able to provide accurate and reliable measurements even in the presence of high-power switching such as in motor control applications. The fail-safe functions including input common-mode overvoltage detection and missing VDD1 detection simplify system-level design and diagnostics.
Product Specification
|
isolation voltage
|
5.0kVRMS |
|
linear Input Voltage Range
|
|
|
High CMTI
|
±150kV/us
|
| Wide operating temperature range |
‐40°C to 125°C |
| Applications |
Shunt current monitoring
AC motor controls
Power and solarinverters
Uninterruptible Power Suppliers
Automotive onboard chargers
|
|
|
| Package options |
|
|
|
Features
Up to 5000Vrms Insulation voltage
±250mV linearInput Voltage Range
Fixed Gain: 8
Low Offset Error and Drift: ±0.5mV (Max), -4~4μV/℃ (Max)
Low Gain Error and Drift: ±0.3% (Max), ±50ppm/℃ (Max)
Low Nonlinearity and Drift: ±0.03% (Max), ±1ppm/℃ (Typ)
SNR: 86dB (Typ, BW=10kHz), 72dB (Typ, BW=100kHz)
Bandwidth: 100kHz(Typ) High CMTI: 150kV/μs(Typ)
System-Level Diagnostic Features:
VDD1 monitoring
Input common-mode overvoltage detection
Operation Temperature: -40℃ ~125℃
AEC-Q100 qualified for automotive applications
RoHS-Compliant Packages: SOP8(300mil) DUB8
Applications
Shunt current monitoring
AC motor controls
Power and solarinverters
Uninterruptible Power Suppliers
Automotive onboard chargers
