NSi83085 Isolated Half- and Full-Duplex RS-485 Transceivers
NSi83085 Isolated Half- and Full-Duplex RS-485 Transceivers

NSi83085 Isolated Half- and Full-Duplex RS-485 Transceivers

NSi83085 is a Replacement parts of ADM2483BRW/ADM2483BRW-REEL/ADM2483BRWZ/ADM2483BRWZ-REEL/ADM2486BRWZ/ADM2486BRWZ-REEL/ISO3082DW/ISO3082DWG4/ISO3082DWR/ISO3082DWRG4/ISO3088DW/ISO3088DWG4/ISO3088DWR/ISO3088DWRG4/ISO1410BDW/ISO1410BDWR/ISO1410DW/ISO1410DWR/ISO1430BDW/ISO1430BDWR/ISO1430DWR/ISO1430DW/ISO1450BDW/ISO1450BDWR/ISO1450DW/ISO1450DWR



NSi83085 has good quality and a cheaper price, which can effectively help you reduce costs and make your products more competitive. In addition, we have sufficient supply and stable price of this parts, which can greatly help you to avoid problems such as price increases and parts shortages of similar products from other brands.

  • Mfr.Part No. :

    NSi83085

  • Manufacturer :

    NOVOSENSE

  • Description :

    High Reliability Isolated Half- and Full-Duplex RS-485 Transceivers

  • Packaging :

    Reel

  • Package :

    SOIC16

  • Stock :

    in stock

  • Price :

    $0.5-$1.5
Inquiry now DataSheet



NSi83085

Price: $0.5-$1.5 $1.5-$2.2 $3.9-$4.1
Replace parts:
Replacement parts:
Alternative parts:
Pin to pin parts:
 NSi83085
ISO3082DW
ISO3082DWG4
ISO3082DWR
ISO3082DWRG4
ISO3088DW
ISO3088DWG4
ISO3088DWR
ISO3088DWRG4
ISO1410BDW
ISO1410BDWR
ISO1410DW
ISO1410DWR
ISO1430BDW
ISO1430BDWR
ISO1430DWR
ISO1430DW
ISO1450BDW
ISO1450BDWR
ISO1450DW
ISO1450DWR

ADM2483BRW
ADM2483BRW-REEL
ADM2483BRWZ
ADM2483BRWZ-REEL
ADM2486BRWZ
ADM2486BRWZ-REEL






Product Specification:
NSi83085 is a high reliability isolated half duplex RS-485 transceiver based on NOVOSENSE digital isolation technology, while NSi83086 is an isolated full duplex RS-485 transceiver. Both devices are safety certified by UL1577 support 5kVrms insulation withstand voltages, while providing high electromagnetic immunity and low emissions at low power consumption. The Bus pins of NSi83085/NSi83086 are protected from ±16kV system level ESD to GND2 on Bus side. These devices feature fail-safe circuitry, which guarantees a
logic-high receiver output when the receiver inputs are open or shorted. The devices have a 1/8-unit-load receiver input impedance that allows up to 256 transceivers on the bus.The data rate of NSi83085 is 500kbps. The device is slew limited to reduce EMI and reflections with improperly terminated transmission line. The data rate of NSi83086 is up to 16Mbps.




Features:

 Up to 5000Vrms Insulation voltage
 Bus side power supply voltage: 3.0V to 5.5V
 VDD1 supply voltage: 2.5V to 5.5V
 High CMTI: ±150kV/us
 High system level EMC performance: Bus Pins meet IEC61000-4-2 ±16kV ESD Other Pins meet ±7kV contact ESD
 Fail-safe protection receiver
 NSi83085 has slew rate limitation
 Up to 256 transceivers on the bus
 Isolation Barrier Life: >60 years
 Operation temperature: -40℃~105℃
 RoHS-compliant packages:
SOIC-16 wide body



Applications



 Industrial automation system
 Isolated RS-485 communication
 Smart electric meter and water meter
 Security and protection monitoring



Packing & Delivery:



1. Shipping Method: Express (SF Express, DHL, TNT, FedEx, etc.), shipping charges are paid by the buyer.

2. Packaging Method: pressure-proof, moisture proof, shock-proof packaging.

3. Shipping Time: In stock items: 3-5 days. Lead Time orders: 45-65 days.



ONE-STOP Electronic Parts Supply Chain:



1. 18 years of experience in the electronic components industry, Our online service provided by over 80+ sales and technical.
2. Serving over 4500 global customers, Annual sales exceeding 50 million USD, and has an upward trend every year.
3. In recent years, many of our clients have adopted Chinese chip brands, reducing costs.
4. We guarantee the quality of each chip and can also provide samples for customers to test, addressing their concerns.
5. Our Produc ime incudes MCU, lsolators, Transceiver,lsolation Power IC, Driver IC, Amplner, Analog Swtch, Comparator, Translator, Gate lc, Sensorpower devices, etc.
