RS1G86XC5
| Price: |
$0.05-$0.15 |
$0.18-$0.25 |
Replace parts:
Replacement parts:
Alternative parts:
Pin to pin parts:
|
RS1G86XC5 |
SN74LVC1G86DCKR
NC7SP86P5X
NC7SZ86P5X
MC74VHC1G86DFT1G
74AHC1G86GW
7UL1G86FU
|
The RS1G86 single 2-input exclusive-OR gate is designed for 1.65V to 5.5V VCC operation.
The RS1G86 device performs the Boolean function Y= A̅ B+ A B̅ in positive logic. The device is fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.
The RS1G86 is available in Green SOT23-5 and SC70-5 packages. It operates over an ambient temperature range of -40°C to +125°C.
• Operating Voltage Range:1.65V to 5.5V
• Low Power Consumption:1µA (Max)
• Operating Temperature Range: -40°C to +125°C
• Inputs Accept Voltage to 5.5V
• High Output Drive: ±24mA at VCC=3.0V
• Micro SIZE PACKAGES: SOT23-5, SC70-5
Applications
• AV Receiver
• Blu-ray Player and Home Theater
• Digital Picture Frame (DPF)
• High-Speed Data Acquisition and Generation
• Personal Navigation Device (GPS)
• Portable Media Player
